Starter for Forklift - The starter motor nowadays is usually either a series-parallel wound direct current electric motor that consists of a starter solenoid, which is similar to a relay mounted on it, or it can be a permanent-magnet composition. As soon as current from the starting battery is applied to the solenoid, mainly via a key-operated switch, the solenoid engages a lever which pushes out the drive pinion that is located on the driveshaft and meshes the pinion using the starter ring gear which is seen on the engine flywheel.
When the starter motor begins to turn, the solenoid closes the high-current contacts. When the engine has started, the solenoid consists of a key operated switch which opens the spring assembly to be able to pull the pinion gear away from the ring gear. This action causes the starter motor to stop. The starter's pinion is clutched to its driveshaft by means of an overrunning clutch. This permits the pinion to transmit drive in just one direction. Drive is transmitted in this manner through the pinion to the flywheel ring gear. The pinion remains engaged, like for example for the reason that the operator fails to release the key when the engine starts or if there is a short and the solenoid remains engaged. This actually causes the pinion to spin independently of its driveshaft.
This above mentioned action stops the engine from driving the starter. This is an important step as this kind of back drive would allow the starter to spin very fast that it can fly apart. Unless modifications were done, the sprag clutch arrangement will stop using the starter as a generator if it was made use of in the hybrid scheme mentioned prior. Normally a standard starter motor is meant for intermittent utilization that would stop it being utilized as a generator.
The electrical parts are made to be able to work for around thirty seconds to stop overheating. Overheating is caused by a slow dissipation of heat is due to ohmic losses. The electrical components are designed to save weight and cost. This is actually the reason nearly all owner's instruction manuals utilized for vehicles suggest the operator to stop for a minimum of ten seconds right after every ten or fifteen seconds of cranking the engine, if trying to start an engine that does not turn over right away.
The overrunning-clutch pinion was introduced onto the marked in the early part of the 1960's. Before the 1960's, a Bendix drive was utilized. This drive system functions on a helically cut driveshaft that has a starter drive pinion placed on it. Once the starter motor starts spinning, the inertia of the drive pinion assembly enables it to ride forward on the helix, thus engaging with the ring gear. When the engine starts, the backdrive caused from the ring gear enables the pinion to exceed the rotating speed of the starter. At this point, the drive pinion is forced back down the helical shaft and therefore out of mesh with the ring gear.
The development of Bendix drive was developed in the 1930's with the overrunning-clutch design called the Bendix Folo-Thru drive, made and introduced in the 1960s. The Folo-Thru drive has a latching mechanism along with a set of flyweights within the body of the drive unit. This was a lot better in view of the fact that the average Bendix drive used so as to disengage from the ring when the engine fired, even if it did not stay running.
The drive unit if force forward by inertia on the helical shaft once the starter motor is engaged and starts turning. Next the starter motor becomes latched into the engaged position. Once the drive unit is spun at a speed higher than what is attained by the starter motor itself, like for example it is backdriven by the running engine, and then the flyweights pull outward in a radial manner. This releases the latch and enables the overdriven drive unit to become spun out of engagement, hence unwanted starter disengagement could be prevented before a successful engine start.
